Scroll Compressor zb21

Technical Specifications:

• Model: ZB21KCE-TFD
• Refrigeration Capacity: Approximately 4.79 kW under nominal conditions with R404A refrigerant, evaporating at -10°C, condensing at 45°C, 10K superheat, and 0°C subcooling.
• Displacement: 8.6 m³/h
• Oil Charge: 1.2 liters
• Oil Type: POE RL32-3MAF
• Net Weight: 29 kg
• Power Supply: 380-420V/3Ph/50Hz
• Maximum Continuous Current (MCC): 7.2 A
• Locked Rotor Amperage (LRA): 40 A
• Maximum Suction Pressure: 21 bar
• Maximum Discharge Pressure: 28.8 bar
• Dimensions: Length: 243 mm, Width: 244 mm, Height: 392 mm
• Suction Connection Thread Diameter: 3/4 inch
• Discharge Connection Thread Diameter: 1/2 inch
• Approved Refrigerants: R22, R134a, R404A, R407C
• Protection Rating: IP21 (IEC34)

Scroll Compressor zb21

The Scroll Compressor zb21 from  ZB21KCE-TFD compressor from Copeland Scroll is designed to satisfy the requirements of contemporary refrigeration systems. It is appropriate for a range of commercial applications because to its scroll design, which guarantees great efficiency and durability. It efficiently manages medium-temperature refrigeration jobs with a displacement of 8.6 m³/h and a refrigeration capacity of roughly 4.79 kW. In order to ensure compatibility with common industrial power systems, the compressor runs on a 380–420V three-phase power supply at 50Hz. With a 1.2-liter charge capacity, it uses POE RL32-3MAF oil, which guarantees the best lubrication and performance. With a net weight of 29 kg and measurements of 243 mm in length, 244 mm in width, and 392 mm in height, the unit’s compact design is clearly visible. The thread diameters used in the design of the suction and discharge connections are To satisfy the requirements of contemporary refrigeration systems, the Copeland Scroll ZB21KCE-TFD compressor was designed. Because of its scroll design, which guarantees great efficiency and longevity, it can be used in a variety of commercial applications. It can handle medium-temperature refrigeration chores with ease because to its 8.6 m³/h displacement and 4.79 kW refrigeration capacity. Compressor compatibility with conventional industrial power systems is ensured by its operation on a 380-420V three-phase power supply at 50Hz. It uses POE RL32-3MAF oil, which has a 1.2-liter charge capacity and guarantees the best possible lubrication and performance. The unit’s measurements of 243 mm in length, 244 mm in width, and 392 mm in height, along with its net weight of 29 kg, demonstrate its compact design. Thread sizes for the suction and discharge connections are designed.
