Rotary Compressors

 Toshiba Gmcc Rotary Compressor PH310M2CS

Model: PH310M2CS-4KTH

Refrigerant: R22

Displacement: 31 cm³/rev

Cooling Capacity: 5,565 W (18,988 BTU/h)

Power Input: 1,750 W

Coefficient of Performance (COP): 3.18 W/W

Voltage: 220-240V, 50Hz, Single Phase

Applications: Suitable for air conditioners, dryers, refrigeration units, chillers, and similar systems

Dimensions:

• Height: 348 mm
• Net Weight: 17.8 kg

Pipe Connections:

• Discharge Pipe Inner Diameter: 9.8 mm
• Suction Pipe Inner Diameter: 12.9 mm

Rotary Compressors

Rotary Compressors The Toshiba GMCC PH310M2CS-4KTH rotary compressor is a popular option in the HVAC sector because of its exceptional efficiency and dependability. Its small size makes it simple to integrate into many systems, and its low vibration and noise levels make it more comfortable for users. Because of its high coefficient of performance, the compressor uses energy efficiently, which lowers operating expenses. It is appropriate for medium-sized air conditioning systems and has a significant cooling capacity of 5,565 W. It is designed to run on R22 refrigerant. Even in the face of extreme conditions, the sturdy structure guarantees longevity and a long service life. The device is compatible with normal electrical systems, having a 1,750 W power input and an operational voltage of 220-240V at 50Hz. Its versatility is demonstrated by the PH310M2CS-4KTH’s ability to be used in a variety of applications, such as air conditioners, dryers, and chillers Rotary Compressors A popular option in the HVAC sector, the Toshiba GMCC PH310M2CS-4KTH rotary compressor is designed for maximum dependability and efficiency. Its low noise and vibration levels improve user comfort, and its small size makes it simple to integrate into a variety of systems. The high coefficient of performance (COP) of the compressor suggests efficient energy use, which lowers operating expenses. With a powerful cooling capability of 5,565 W, it is ideal for medium-sized air conditioning systems and is made to run on R22 refrigerant. Even in the most demanding circumstances, the sturdy design guarantees longevity and a long service life. Adhering to normal electrical standards, it has a 1,750 W power input and operates at 220-240V at 50Hz. Its applicability to a range of applications, such as air conditioners, dryers, and chillers, highlights the PH310M2CS-4KTH’s versatility..
