Scroll Compressor zb26

Technical Specifications:

• Model: ZB26KCE-TFD-558
• Refrigeration Capacity: Approximately 5.41 kW under nominal conditions with R404A refrigerant, evaporating at -10°C, condensing at 45°C, 10K superheat, and 0°C subcooling.
• Displacement: 9.94 m³/h
• Oil Charge: 1.12 liters
• Oil Type: POE RL32-3MAF
• Net Weight: 28.4 kg
• Power Supply: 400V/3Ph/50Hz
• Maximum Continuous Current (MCC): 8.9 A
• Locked Rotor Amperage (LRA): 46.0 A
• Maximum Suction Pressure: 21.0 bar
• Maximum Discharge Pressure: 32.0 bar
• Dimensions: Length: 243 mm, Width: 244 mm, Height: 405 mm
• Suction Connection Thread Diameter: 1 1/4 inch
• Discharge Connection Thread Diameter: 1 inch
• Approved Refrigerants: R22, R134a, R404A, R407A, R407C, R407F, R448A, R449A, R450A, R513A
• Protection Rating: IP21 (IEC34)

Scroll Compressor zb26

The Scroll Compressor  ZB26KCE-TFD compressor by Copeland Scroll was designed to satisfy the requirements of contemporary refrigeration systems. It is appropriate for a range of commercial applications because to its scroll design, which guarantees great efficiency and durability. It efficiently manages medium-temperature refrigeration chores with a displacement of 9.94 m³/h and a refrigeration capacity of roughly 5.41 kW. In order to ensure compatibility with common industrial power systems, the compressor runs on a 400V, three-phase power source at 50Hz. With a 1.12 liter charge capacity, it uses POE RL32-3MAF oil, which guarantees the best lubrication and performance. With a net weight of 28.4 kg and measurements of 243 mm in length, 244 mm in width, and 405 mm in height, the unit’s compact design is clearly visible. The thread diameters used in the design of the suction and discharge connections are In order to satisfy the requirements of contemporary refrigeration systems, the Copeland Scroll ZB26KCE-TFD compressor was designed. Because of its scroll design, which guarantees great efficiency and longevity, it can be used in a variety of commercial applications. It can handle medium-temperature refrigeration chores with ease because to its 9.94 m³/h displacement and 5.41 kW refrigeration capacity. The compressor runs at 50 Hz on a 400V, three-phase power source, making it compatible with common industrial power systems. It uses POE RL32-3MAF oil, which has a 1.12 liter charge capacity and guarantees the best possible lubrication and performance. The unit’s 243 mm length, 244 mm width, and 405 mm height, as well as its net weight of 28.4 kg, demonstrate its compact design.
